Cold Work Steel

Home › Products › Die & Tool Steel › Cold Work Steel
Inquiry Now

Product Description

Various properties of Cold Work Steels make them perfect for manufacturing a variety of products such as cutting and pressing tools, cavity moulds, knives, hobbing and drawing tools, cavity-sinking punches, flat and circular thread-rolling dies, and much more. Having all such properties like high surface hardness, good toughness and compressive strength, high wear resistance the Cold Work Steel that we offer is highly demanded. Tool & Die Steel is one of major Strengths, We are a Leading Importer - Exporter - Stockist of these Steel Products. WE offer Wide range of Sizes for this Steel.

Suited For
  • Cutting dies
  • Heavy duty cutting and Punching tools
  • Milling cutters
  • Reamers
  • Calipers
  • Tapping dies
  • Measuring tools

Technical Specifications

Grade % C Mn Si Cr Mo V W S P Co
AISI 01 Min 0.85 1.00 0.20 0.40 Max 0.40 Max Max -
Max 0.95 1.30 0.40 0.60 - 0.20 0.60 0.015 0.020 -
AISI D2 (DIN 1.2379) Min 1.40 0.30 0.30 11.00 0.70 0.90 - Max Max Max
Max 1.60 0.50 0.50 13.00 1.20 1.10 - 0.015 0.020 0.6
AISI D3 (DIN 1.2080) Min 2.00 0.24 0.25 11.00 - Max Max Max Max -
Max 2.35 0.45 0.45 13.00 - 0.80 0.75 0.015 0.020 -
